Industrial Panel All-In-One PC: 13.3″ & 15.6″ with Capacitive Touch Screen, WiFi, Windows 10 Pro

Description

Enclosed flat-screen capacitive touch industrial computer 13.3 15 15.6 18.5 Inch All In One PC
13.3 inch(1366×768)/15 inch(1024×768)/15.6 inch(1366×768)/18.5 inch(1366×768)
Industrial computer parameters
Brand：Balahome
Aterial：aluminium alloy
Memory: optional 4GB/8GB DDR3 System Memory
Storage: optional 64GB/128GB /256GB SDD/512GB SDD
Operating system: Windows 7, Windows 8, Windows 10, Linux, XP
Motherboard size: 170mm*170mm
Graphic: IntelHD Graphics
Color: black (customizable color)
Weight: about 5-7Kgs
System Parameter：
1. Intel Core i3-3217U（Dual core, 3MB cache, 1.80 GHz，TDP power consumption：17w）
2. Intel Core i5-3337U（Dual core, 3MB cache, 1.80 GHz，TDP power consumption: 17w）
3. Core i7-3537U（Dual core, 4MB cache, 2.00 GHz，TDP power consumption: 17w）
4. Intel Core i3-5010U（Dual-core, 3MB cache, 2.1 GHz，TDP power consumption: 15w）
5. Intel Core i5-5200U（Dual-core, 3MB cache, 2.2-2.7 GHz，TDP power consumption: 15w）
6. Intel Core i7-5500U（Dual-core, 4MB cache, 2.4-3.0 GHz，TDP power consumption: 15w）
7. Intel Core i3-6100U（Dual-core, 3MB cache, 2.3 GHz，TDP power consumption: 15w）
8. Intel Core i5-6200U（Dual-core, 3MB cache, 2.3-2.8 GHz，TDP power consumption: 15w）
9. Intel Core i7-6500U（Dual-core,4MB cache, 2.5-3.1 GHz，TDP power consumption: 15w）
Parameters of LCD Touch screen：
Brightness：300cd/m2 （Can be customized for higher brightness）
Contrast Ratio：1000: 1
Viewing Angle：Horizontal(left/right): 150°(75°/75°)
Vertical(up/down): 150°(75°/75°)
Response Time：30 (Typ. )(Tr+Td) (ms)
Frame Rate：60Hz
Color system：PAL/ NTSC
Interface：1 x VGA + 1 x HDMI + 2 * COM (default 232 protocol interface) +1 x RJ45 + 4 * USB + 1 x audio
Power requirement of system：+ 12V DC power input
Power adapter：input：100〜250VAC，50 / 60Hz
Output：60W Adapter（12V 5A）
Working temperature：-20°C〜60°C
Relative humidity：0％〜90％relative humidity, no condensatio
Plug：AU, EU, USA, UK plug available
Menu Languages：English, , Francais, Italiano, Deutsch, Espanol, Russian, Traditional Chinese, Simplified Chinese, etc
VISA Hole distance：75*75mm
Delivery Time
Sample: 1~5 working days.
10~100pcs: 2~7 working days.
More than 100pcs: 5~15 working days
★★★ SPECIAL REMINDER ★★★
LOGO/Product Model/Case Material/Add Touch Function/Add Built-in Speaker/Add Remote Control Function/Base Style/Screen Size/Interface Type/Power Type/Installation Mode(Wall-hang/Embedded/Open-frame), etc. , can be customized for you(But need to meet the requirements of MOQ). If you have this demand, please contact us, we will provide you with timely and thoughtful service!
Size
Resolution: 17 inch(1280×1024)/19 inch(1280×1024)/21.5inch(1920×1080)
Unit of measure: mm
Product interface (support customization)
1 x VGA + 1 x HDMI + 2 * COM (default 232 protocol interface, please contact us to customize 485 protocol interface) +1 x RJ45 + 4 * USB + 1 x audio
Front panel With Dust and water resistant Functionality
Dust, water and oil resistant to break through environmental restrictions, more suitable for use in the harsh environment of industrial automation equipment
Sensitive Touch Rapid Response
Capacitive touch times > 50 million times, backlight life 50000h
Support a variety of gesture touch, sensitive response, stable touch.
Sensitive touch makes it easier to use.
The sensing accuracy is higher, the response speed is faster, and the surface has a smooth or matte surface treatment.
Support more refined industrial operation touch, no blind spot
Installation Mode-1
1. Embedded installation
①The cabinet needs to be opened before installation, and the opening size should be slightly larger than the opening size specified by the product.
②Place the product in the embedded installation opening reserved on the installation panel.
③There are two square holes on both sides of the equipment. When installing, use one end of the buckle to buckle the square hole, and the screw head on the buckle to hold the cabinet.
Then tighten the screws, the installation method of the other three prescription holes is the same, and the embedded installation can be completed.
Installation Mode-2
There are eight small holes behind the product, the distance between the four installation holes inside is 75mm x 75mm, and the outside four mounting holes are 100mm x 100mm, equipped with wall hanging installation accessories and embedded installation accessories, the installation mode is flexible, and the following installation methods are for reference only.
Industrial-grade custom motherboard
A variety of industrial motherboards are available, with high-performance processors and low noise consumption. First choice for industrial use, stable operation in harsh environments.
The machine runs stably
24/7 stable operation
Efficient work for a long time, fast cooling
Metal case, resist to high and low temperature environment
Industrial cold-rolled sheet metal shell, cold and high temperature resistance, as low as -20 ℃ ~ 60 ℃.
Can effectively adapt to stable work in harsh environments
About customization
Please contact customer service to state your needs.
Support logo, shell, color, function, interface and other customization, please contact us for the best price
Product application field display
Products are widely used in industrial control CNC industry, medical industry, factory production workshop,
Bank automatic ticket vending machines, supermarket advertising, video surveillance, etc.
