Qotom Core i3 Mini PC with Dual-Core 1.7 GHz I3-4005U Processor, Onboard Dual Band WiFi, BT4.0 – Fanless Small Desktop Computer.

Description

Qotom Mini PC Q330P
• Dimensions: 187 x 111 x 50mm
• Net Weight: 0.9 KG
• Material: Aluminum alloy Shell
• Mounting: VESA Mounting Bracket
• Cooling Mode: Fanless Design
• Operating Temp: 0°C~50°C
• Packing: Standard export packing
CPU Core i3-4005U onboard:
• Intel Core i3-4005U Processor, 3M Cache, dual core 1.7 GHz
• CPU TDP: 15W
• Processor Graphics: Intel HD Graphics 4400
• Intel Virtualization Technology (VT-x): Yes
• Intel Virtualization Technology for Directed I/O (VT-d): No
• Intel AES New Instructions: Yes
• Secure Key: Yes
Ports
Front I/O
• Power Button
• 2 x USB 2.0 Ports
• 2 x USB 3.0 Ports
• 1 x Power LED
• 1 x HDD LED
• 2 x Serial Ports (RS-232)
Rear I/O
• 1 x DC Jack
• 2 x HD Video Ports
• 2 x Intel i210-AT Gigabit LAN Ports
• 2 x USB 3.0 Port
• 4 x Serial Ports
• Mic-in, Line-out
• Wi-Fi (Optional)
Operating System
• Preinstall inactive Windows 10 for test and do not supply license.
• It supports Windows 7/ 8/ 10, Linux, etc.
• F11 key boot from USB Drive. Delete key enter BIOS.
Custom Services:
6 COM (RS-232) by default.
If you need RS485 or VGA, or remove some COM Ports, please leave a message. Same price, same delivery date.
Option 1: 6 x RS232 (Defalult)
Option 2: 5 x RS232, 1 x VGA
Option 3: 5 x RS232, 1 x RS485
Option 4: 4 x RS232, 1 xRS485, 1 x VGA
Fanless Mini motherboard
Memory:
1 x DDR3 DIMM Memory Slot
Support DDR3L 1333/1600 MHz, 1.35V
Max: 8GB
Non-ECC
Storage:
Support SSD (MSATA / SATA)
Support HDD (2.5 inch SATA HDD)
Wi-Fi:
1 x Half mini pcie slot for Wi-Fi
Interface: PCIE
Packing
1 x Mini PC
1 x Power supply (adapter and cord)
1 x VESA bracket & screws
1 x color box
* Power cord options: EU/ SA/ AU/ US/ CH Type
* Dual antennas if you buy Wi-Fi
* If you need neutral packaging box, tell us in advance.
* Contact us if you need Motherboard User Manual and Windows drivers.
