PL2303 USB-3.5mm Stereo RS232 Flash Cable for FreeSAT V8, GTMedia V7 V8 Upgrade Flashing Lead – Win11 Compatible

Description

IPTV RS232 Console Cable
FreeSAT V8 Flash Cable Support Send UPG2.2 V2.2
Password Recover Firmware Upgrade Lead
PL2303 USB RS232 Firmware Updating DVBS Recovery Cable
Please install the USB RS232 VCP driver before using
Support Win XP/7/8/10/11
28AWG*3C Pure copper(white-TXD, green-RXD, Black-GND)
60P PVC Jacket soft cable, OD3.8mm
3.5mm TRS plugs pinout(TV TX-PC RX, TV RX-PC TX):
Intergrated Original PL2303TA chip, support Win7/8/10/11(Pls contact us for special driver for Win11, Prolific dirver donot support win11)
PL2303TA provides a convenient solution for connecting an RS232-like full-duplex asynchronous serial device to any Universal Serial Bus (USB) capable host. PL2303TA highly compatible drivers could simulate the traditional COM port on most operating systems allowing the existing applications based on COM port to easily migrate and be made USB ready without having to rewrite the COM port software application.
By taking advantage of USB bulk transfer mode, large data buffers, and automatic flow control, PL2303TA is capable of achieving higher throughput compared to traditional UART (Universal Asynchronous Receiver Transmitter) ports. When real RS232 signaling is not required, baud rate higher than 115200 bps could be used for even higher performance. The flexible baud rate generator of PL2303TA could be programmed to generate any rate between 75 bps and 6M bps.
PL2303TA is exclusively designed for mobile and embedded solutions in mind, providing a small footprint that could easily fit in to any connectors and handheld devices. With very small power consumption in either operating or suspend mode, PL2303TA is perfect for bus powered operation with plenty of power left for the attached devices. Flexible signal level requirement on the RS232-like serial port side also allows PL2303TA to connect directly to any 3.3V~1.8V range devices.
Features:
1. Full Compliant with USB Specification v2.0(full speed)
2. USF-IF Logo Compliant with TID 40001305
3. Support RS232 like Serial UART Interface
. Full-duplex transmitter and receiver(TXD and RXD)
. Support CTS/RTS on-board
.5,6,7 or 8 data bits
. Odd, Even, Mark, Space, or None parity mode
. One, one and a half, or two stop bits
. Parity error, frame error, and serial break detection
. Programmable baud rate from 75bps to RS232 256K bps
. External RS232 driver power down control
. Automatic Hardware flow control with CTS/RTS
. Automatic software flow control with XON/XOFF
.256-byte outbound buffer and 256 inbound buffer
. Support remote wake up from RS232 input pin signals(RI, RXD, DCD, CTS)
. Support Chip Suspend on Power State
. Support USB Selective Suspend
. Support Win 2000/XP, Vista and 7/8/10, NOT support Win11
. Mac OS8/9 OS X Linux/Android Kernel2.4.31 above
. Provides Driver Customization for Customer VID/PID and special bard rates
4 UHCI/OHCI(USB1.1), EHCI(USB2.0), xHCI(USB3.0) Host Controller Compatible
5. Low Operation Power Consumption and Suspend Current
Support Win11 Win10 PL2303 USB-3.5mm Stereo for FreeSAT V8 Flash Cable GTMedia V7 V8 Upgrading Flashing Lead
